Applications
- Smell and corrosion control in industrial and commercial applications
- Kitchen ventilation
- Wide range of molecular contamination issues
Highlights
- High efficiency in gas filtration
- Pellet (granulated) activated carbon
- Robust and air tight
- Filled with a wide variety of activated carbon medias including impregnated medias
- Filled on vibration table to prevent any space
Technical Specifications
| Media: | Activated Carbon Impregnated Medias | Gasket: | Standard for cartridge | |
| Frame: | Galvanized and painting steel | Outer Diameter: | 145 mm | |
| Max. Operating Temperature: | 50°C | Recommended relative humidity: | < 70% RH |
Order Code
| Filter Type | Frame | Outer Diameter | Capacity | Media | Length |
|---|---|---|---|---|---|
| CR : Activated Carbon Single Cartridge | P: Powder Coated G: Galvanized Metal | 145 | N: Normal H: High | AC: Activated Carbon +11: 11% Potassium Permanganate +11/AC: 11% Potassium Permanganate +AC KOH: Potassium Hydroxide Kl4%: Potassium Iodide ACPA: Phosphoric Acid S: Sulphur TB: Triple Blend (KOH + AC + 11%) Z: Special | 400 450 600 |
| Cartridge Model (Single) | Cartridge Type | Cartridge Volume (dm³) | Cartridge Airflow (m³/h) |
|---|---|---|---|
| CR-G-145-N-AC-400 | N | 3.9 | 150 |
| CR-G-145-N-AC-450 | N | 44 | 160 |
| CR-G-145-N-AC-600 | N | 5.9 | 212.5 |
| CR-G-145-H-AC-400 | H | 4.7 | 150 |
| CR-G-145-H-AC-450 | H | 5.3 | 160 |
| CR-G-145-H-AC-600 | H | 7 | 212.5 |
